Kia PV5 Cargo S Long Range Charging Speed, Time and Cost
Van · 2026 – CurrentFBT exemptV2L
- Usable Battery
- 67kWh
- AC Charging
- 10.5kW
- DC Charging
- 128kW
- 10–80% Time
- 30min
The Kia PV5 Cargo S Long Range charges at up to 128 kW on a DC fast charger and 10.5 kW on AC. It takes about 30 minutes to charge from 10 to 80% and 10.1 hours to charge from empty on a 7 kW home charger. It has a 67 kWh NMC battery.
Kia PV5 Cargo S Long Range Key Battery and Charging Specs
| Usable Battery | 67 kWh |
|---|---|
| Battery Chemistry | NMC |
| Charge Port | Type 2 (AC), CCS2 (DC) |
| Charge Port Location | Front Center |
| 0 to 100% at Home (7 kW) | 10.1 hrs |
| Efficiency | 191 Wh/km |
The Kia PV5 Cargo S Long Range uses a 67 kWh NMC battery. For daily driving, charge to 80 to 90% and save 100% for long trips (LFP vs NMC vs NCA batteries explained). Check your owner's manual for Kia's advice.
Compare the best home EV charger in Australia and work out how much electric car charging costs for your driving.
Kia PV5 Cargo S Long Range Charging Times
Kia PV5 Cargo S Long Range Max Charging Speed
| Type | Max Speed |
|---|---|
| AC charging speed | 10.5 kW |
| DC charging speed (peak) | 128 kW |
How Long Does a Kia PV5 Cargo S Long Range Take to Charge?
| Charger | Power Used | Time | Range Added |
|---|---|---|---|
| 10A power point (2.3 kW) | 2.3 kW | 30.8 hrs (0 to 100%) | 12 km per hour |
| 15A power point (3.6 kW) | 3.6 kW | 19.7 hrs (0 to 100%) | 19 km per hour |
| 7 kW home wall charger | 7 kW | 10.1 hrs (0 to 100%) | 37 km per hour |
| 11 kW three-phase charger | 10.5 kW | 6.8 hrs (0 to 100%) | 55 km per hour |
| 50 kW DC fast charger | 47.5 kW | 59 min (10 to 80%) | 62 km in 15 min |
| 150 kW DC fast charger | 94 kW | 30 min (10 to 80%) | 123 km in 15 min |
Icons: grey = power point, green outline = home charger, dark = public DC fast charger.
Best Home Charger for the Kia PV5 Cargo S Long Range
A 7 kW single-phase wall charger suits the Kia PV5 Cargo S Long Range. It charges the battery from empty to full in 10.1 hrs and adds about 37 km of range every hour.
Find the Right Charger for Your Kia PV5 Cargo S Long Range
See the real charging speed each home charger gets with this car. 3 quick questions.
| Detail | 7 kW Single Phase |
|---|---|
| 0 to 100% | 10.1 hrs |
| Range per hour | 37 km |
| Needs three-phase power | No |
| Typical installed cost | $1,200 to $2,800 |
Installed costs are indicative for Australia and include the charger and standard installation. A switchboard upgrade, if needed, can add $900 to $3,500.
Does the Kia PV5 Cargo S Long Range Come With a Charger?
New EVs like the Kia PV5 Cargo S Long Range normally come with a complimentary portable charger that plugs into a standard 10A power point. It's handy for top-ups but takes about 30.8 hrs to fully charge the battery. A 7 kW wall charger does it in 10.1 hrs.
How Much Does It Cost to Charge a Kia PV5 Cargo S Long Range?
A full charge costs $4.69 at home on an EV plan at $0.07/kWh, and $23.45 on a typical flat tariff of $0.35/kWh. At a public DC charger at up to $0.70/kWh it costs $46.90. A petrol mid-size van uses about 7.6 L/100 km, which at $2.00 a litre costs $15.20 per 100 km.
| Where You Charge | Full Charge | Per 100 km | Per Year | Saving vs Petrol |
|---|---|---|---|---|
| Petrol mid-size van | Not applicable | $15.20 | $2,280 | Not applicable |
| Home, flat rate $0.35/kWh | $23.45 | $6.69 | $1,003 | $1,277 |
| Home, EV plan $0.07/kWh | $4.69 | $1.34 | $201 | $2,079 |
| Public DC $0.70/kWh | $46.90 | $13.37 | $2,006 | $274 |
Icons: grey = petrol, green outline = home charging, dark = public charging.
Per year is based on 15,000 km a year.
Switching from a flat tariff to an EV plan saves about $802 a year on charging the Kia PV5 Cargo S Long Range at home.
Kia PV5 Cargo S Long Range Fast Charging Rank and Road Trip Charging
The Kia PV5 Cargo S Long Range ranks 1 of 9 van EVs priced within $10,000 of it for DC fast charging power.
| Rank | Vehicle | Price | Peak DC (kW) | 10–80% time |
|---|---|---|---|---|
| 1 | Kia PV5 Cargo S Long Range | $55,990 | 128 | 30 min |
| 2 | Farizon V7E SR | $49,990 | 100 | 21 min |
| 2 | Farizon V7E LR | $53,990 | 100 | 35 min |
| 2 | Peugeot e-PARTNER Test | $59,990 | 100 | 26 min |
| 2 | Peugeot e-PARTNER | $59,990 | 100 | 26 min |
Kia PV5 Cargo S Long Range 500 km and 1,000 km Road Trips
Using Zecar's estimated highway range of 304 km and an average of 100 km/h: A 500 km trip needs 2 fast charging stops of about 30 minutes each, 1 hr in total, for a total trip time of about 6 hr. A 1,000 km trip needs 4 fast charging stops of about 30 minutes each, 2 hr in total, for a total trip time of about 12 hr.
| Trip | Charging stops | Charging time | Total trip time |
|---|---|---|---|
| 500 km | 2 | 1 hr | 6 hr |
| 1,000 km | 4 | 2 hr | 12 hr |
Total trip time is driving at an average of 100 km/h plus charging time. Estimates assume a start at 100%, arrival at no less than 10% and charging from 10% to 80% at a 128 kW-capable charger. Real times vary with weather, speed, load and charger.
Plan your trip costs with the EV charging calculator →Kia PV5 Cargo S Long Range Bidirectional Charging (V2X): V2L, V2H and V2G
- V2L powers appliances from the car's socket.
- V2H powers your home during an outage or peak pricing.
- V2G sends energy back to the grid.
| Feature | Supported | Max Output |
|---|---|---|
| V2L | Yes | 3.6 kW |
| V2H | No | |
| V2G | No |
The Kia PV5 Cargo S Long Range supports V2L and can power appliances up to 3.6 kW. It does not support V2H or V2G.
Kia PV5 Cargo S Long Range Deals and Finance
Pricing starts from $55,990. A novated lease lets you pay for the car and its running costs from your pre-tax salary, and eligible EVs are exempt from fringe benefits tax. How the EV FBT exemption works
Get a Novated Lease QuoteKia PV5 Cargo S Long Range Charging FAQ
10.1 hrs for 0 to 100% on a 7 kW home charger, and 30 minutes for 10 to 80% at a DC charger of 128 kW or more.
10.5 kW on AC and 128 kW on DC, adding about 123 km of range in 15 minutes on a fast charger.
Type 2 for AC and CCS2 for DC, on the front center.
$4.69 at home on an EV plan, $23.45 on a flat tariff, or $46.90 at a public DC charger (compare EV energy plans).
Yes, at Superchargers open to non-Tesla EVs, using its CCS2 plug, so check the Tesla app for which sites are open.
Yes, up to 3.6 kW, but it doesn't support V2H or V2G.
