Kia EV5 Air Long Range

Kia EV5 Air Long Range Charging Speed, Time and Cost

Medium SUV · 2024 – CurrentFBT exemptV2L

Usable Battery
81kWh
AC Charging
11kW
DC Charging
140kW
10–80% Time
38min

The Kia EV5 Air Long Range charges at up to 140 kW on a DC fast charger and 11 kW on AC. It takes about 38 minutes to charge from 10 to 80% and 12.2 hours to charge from empty on a 7 kW home charger. It has a 81 kWh LFP battery.

Kia EV5 Air Long Range Key Battery and Charging Specs

Kia EV5 Air Long Range battery and charging specs
Usable Battery81 kWh
Battery ChemistryLFP
Charge PortType 2 (AC), CCS2 (DC)
Charge Port LocationRight Side (Front)
0 to 100% at Home (7 kW)12.2 hrs
Efficiency146 Wh/km

The Kia EV5 Air Long Range uses a 81 kWh LFP battery. LFP batteries handle regular charging to 100% with less wear than other chemistries (LFP vs NMC vs NCA batteries explained). Check your owner's manual for Kia's advice.

Compare the best home EV charger in Australia and work out how much electric car charging costs for your driving.

Kia EV5 Air Long Range Charging Times

Kia EV5 Air Long Range Max Charging Speed

Kia EV5 Air Long Range maximum charging speed
TypeMax Speed
AC charging speed11 kW
DC charging speed (peak)140 kW

How Long Does a Kia EV5 Air Long Range Take to Charge?

Power point, wall charger and DC fast charger for the Kia EV5 Air Long Range
Kia EV5 Air Long Range charging times by charger
ChargerPower UsedTimeRange Added
10A power point (2.3 kW)2.3 kW37.3 hrs (0 to 100%)16 km per hour
15A power point (3.6 kW)3.6 kW23.8 hrs (0 to 100%)25 km per hour
7 kW home wall charger7 kW12.2 hrs (0 to 100%)48 km per hour
11 kW three-phase charger11 kW7.8 hrs (0 to 100%)75 km per hour
50 kW DC fast charger47.5 kW72 min (10 to 80%)81 km in 15 min
150 kW DC fast charger89.5 kW38 min (10 to 80%)153 km in 15 min

Icons: grey = power point, green outline = home charger, dark = public DC fast charger.

Best Home Charger for the Kia EV5 Air Long Range

A 7 kW single-phase wall charger suits the Kia EV5 Air Long Range. It charges the battery from empty to full in 12.2 hrs and adds about 48 km of range every hour. If your home already has three-phase power, an 11 kW charger uses the Kia EV5 Air Long Range's full AC speed and charges it in 7.8 hrs.

Find the Right Charger for Your Kia EV5 Air Long Range

See the real charging speed each home charger gets with this car. 3 quick questions.

Home chargers for the Kia EV5 Air Long Range
Detail7 kW Single Phase11 kW Three Phase
0 to 100%12.2 hrs7.8 hrs
Range per hour48 km75 km
Needs three-phase powerNoYes
Typical installed cost$1,200 to $2,800$1,800 to $3,500 with existing three-phase power. $4,000 to $12,000+ if your home needs converting

Installed costs are indicative for Australia and include the charger and standard installation. A switchboard upgrade, if needed, can add $900 to $3,500.

Does the Kia EV5 Air Long Range Come With a Charger?

New EVs like the Kia EV5 Air Long Range normally come with a complimentary portable charger that plugs into a standard 10A power point. It's handy for top-ups but takes about 37.3 hrs to fully charge the battery. A 7 kW wall charger does it in 12.2 hrs.

How Much Does It Cost to Charge a Kia EV5 Air Long Range?

A full charge costs $5.67 at home on an EV plan at $0.07/kWh, and $28.35 on a typical flat tariff of $0.35/kWh. At a public DC charger at up to $0.70/kWh it costs $56.70. A petrol medium SUV uses about 10.2 L/100 km, which at $2.00 a litre costs $20.40 per 100 km.

Cost to charge the Kia EV5 Air Long Range compared with a petrol medium SUV
Where You ChargeFull ChargePer 100 kmPer YearSaving vs Petrol
Petrol medium SUVNot applicable$20.40$3,060Not applicable
Home, flat rate $0.35/kWh$28.35$5.11$767$2,293
Home, EV plan $0.07/kWh$5.67$1.02$153$2,907
Public DC $0.70/kWh$56.70$10.22$1,533$1,527

Icons: grey = petrol, green outline = home charging, dark = public charging.

Per year is based on 15,000 km a year.

Switching from a flat tariff to an EV plan saves about $614 a year on charging the Kia EV5 Air Long Range at home.

Kia EV5 Air Long Range Fast Charging Rank and Road Trip Charging

The Kia EV5 Air Long Range ranks 25 of 33 medium SUV EVs priced within $10,000 of it for DC fast charging power.

DC fast charging rank for medium SUV EVs priced near the Kia EV5 Air Long Range
RankVehiclePricePeak DC (kW)10–80% time
1XPENG G6 RWD Long Range$56,80045112 min
1XPENG G6 AWD Performance$63,80045112 min
3Smart #5 Pro+$58,90040018 min
3Smart #5 Premium$63,90040018 min
5IM IM6 Platinum$69,99039621 min
25Kia EV5 Air Long Range$61,17014038 min

Kia EV5 Air Long Range 500 km and 1,000 km Road Trips

Using Zecar's estimated highway range of 433 km and an average of 100 km/h: A 500 km trip needs 1 fast charging stop of about 38 minutes, for a total trip time of about 5 hr 38 min. A 1,000 km trip needs 3 fast charging stops of about 38 minutes each, 1 hr 54 min in total, for a total trip time of about 11 hr 54 min.

Estimated road trip charging for the Kia EV5 Air Long Range
TripCharging stopsCharging timeTotal trip time
500 km138 min5 hr 38 min
1,000 km31 hr 54 min11 hr 54 min

Total trip time is driving at an average of 100 km/h plus charging time. Estimates assume a start at 100%, arrival at no less than 10% and charging from 10% to 80% at a 140 kW-capable charger. Real times vary with weather, speed, load and charger.

Plan your trip costs with the EV charging calculator →

Kia EV5 Air Long Range Bidirectional Charging (V2X): V2L, V2H and V2G

  • V2L powers appliances from the car's socket.
  • V2H powers your home during an outage or peak pricing.
  • V2G sends energy back to the grid.
Kia EV5 Air Long Range bidirectional charging support
FeatureSupportedMax Output
V2LYes3.6 kW
V2HNo
V2GNo

The Kia EV5 Air Long Range supports V2L and can power appliances up to 3.6 kW. It does not support V2H or V2G.

Kia EV5 Air Long Range Deals and Finance

Pricing starts from $61,170. A novated lease lets you pay for the car and its running costs from your pre-tax salary, and eligible EVs are exempt from fringe benefits tax. How the EV FBT exemption works
