Volvo EX40 Ultra Single Motor Extended Range

Volvo EX40 Ultra Single Motor Extended Range Charging Speed, Time and Cost

Small SUV · 2024 – CurrentFBT exempt

Usable Battery
79kWh
AC Charging
11kW
DC Charging
200kW
10–80% Time
28min

The Volvo EX40 Ultra Single Motor Extended Range charges at up to 200 kW on a DC fast charger and 11 kW on AC. It takes about 28 minutes to charge from 10 to 80% and 11.9 hours to charge from empty on a 7 kW home charger. It has a 79 kWh NMC battery.

Volvo EX40 Ultra Single Motor Extended Range Key Battery and Charging Specs

Volvo EX40 Ultra Single Motor Extended Range battery and charging specs
Usable Battery79 kWh
Battery ChemistryNMC
Charge PortType 2 (AC), CCS2 (DC)
Charge Port LocationLeft Side (Rear)
0 to 100% at Home (7 kW)11.9 hrs
Efficiency137 Wh/km

The Volvo EX40 Ultra Single Motor Extended Range uses a 79 kWh NMC battery. For daily driving, charge to 80 to 90% and save 100% for long trips (LFP vs NMC vs NCA batteries explained). Check your owner's manual for Volvo's advice.

Compare the best home EV charger in Australia and work out how much electric car charging costs for your driving.

Volvo EX40 Ultra Single Motor Extended Range Charging Times

Volvo EX40 Ultra Single Motor Extended Range Max Charging Speed

Volvo EX40 Ultra Single Motor Extended Range maximum charging speed
TypeMax Speed
AC charging speed11 kW
DC charging speed (peak)200 kW

How Long Does a Volvo EX40 Ultra Single Motor Extended Range Take to Charge?

Power point, wall charger and DC fast charger for the Volvo EX40 Ultra Single Motor Extended Range
Volvo EX40 Ultra Single Motor Extended Range charging times by charger
ChargerPower UsedTimeRange Added
10A power point (2.3 kW)2.3 kW36.3 hrs (0 to 100%)17 km per hour
15A power point (3.6 kW)3.6 kW23.2 hrs (0 to 100%)26 km per hour
7 kW home wall charger7 kW11.9 hrs (0 to 100%)51 km per hour
11 kW three-phase charger11 kW7.6 hrs (0 to 100%)80 km per hour
50 kW DC fast charger47.5 kW70 min (10 to 80%)87 km in 15 min
150 kW DC fast charger118.5 kW28 min (10 to 80%)216 km in 15 min
350 kW DC ultra-fast charger118.5 kW28 min (10 to 80%)216 km in 15 min

Icons: grey = power point, green outline = home charger, dark = public DC fast charger.

Best Home Charger for the Volvo EX40 Ultra Single Motor Extended Range

A 7 kW single-phase wall charger suits the Volvo EX40 Ultra Single Motor Extended Range. It charges the battery from empty to full in 11.9 hrs and adds about 51 km of range every hour. If your home already has three-phase power, an 11 kW charger uses the Volvo EX40 Ultra Single Motor Extended Range's full AC speed and charges it in 7.6 hrs.

Find the Right Charger for Your Volvo EX40 Ultra Single Motor Extended Range

See the real charging speed each home charger gets with this car. 3 quick questions.

Home chargers for the Volvo EX40 Ultra Single Motor Extended Range
Detail7 kW Single Phase11 kW Three Phase
0 to 100%11.9 hrs7.6 hrs
Range per hour51 km80 km
Needs three-phase powerNoYes
Typical installed cost$1,200 to $2,800$1,800 to $3,500 with existing three-phase power. $4,000 to $12,000+ if your home needs converting

Installed costs are indicative for Australia and include the charger and standard installation. A switchboard upgrade, if needed, can add $900 to $3,500.

Does the Volvo EX40 Ultra Single Motor Extended Range Come With a Charger?

New EVs like the Volvo EX40 Ultra Single Motor Extended Range normally come with a complimentary portable charger that plugs into a standard 10A power point. It's handy for top-ups but takes about 36.3 hrs to fully charge the battery. A 7 kW wall charger does it in 11.9 hrs.

How Much Does It Cost to Charge a Volvo EX40 Ultra Single Motor Extended Range?

A full charge costs $5.53 at home on an EV plan at $0.07/kWh, and $27.65 on a typical flat tariff of $0.35/kWh. At a public DC charger at up to $0.70/kWh it costs $55.30. A petrol small SUV uses about 7.5 L/100 km, which at $2.00 a litre costs $15.00 per 100 km.

Cost to charge the Volvo EX40 Ultra Single Motor Extended Range compared with a petrol small SUV
Where You ChargeFull ChargePer 100 kmPer YearSaving vs Petrol
Petrol small SUVNot applicable$15.00$2,250Not applicable
Home, flat rate $0.35/kWh$27.65$4.80$719$1,531
Home, EV plan $0.07/kWh$5.53$0.96$144$2,106
Public DC $0.70/kWh$55.30$9.59$1,439$811

Icons: grey = petrol, green outline = home charging, dark = public charging.

Per year is based on 15,000 km a year.

Switching from a flat tariff to an EV plan saves about $575 a year on charging the Volvo EX40 Ultra Single Motor Extended Range at home.

Volvo EX40 Ultra Single Motor Extended Range Fast Charging Rank and Road Trip Charging

The Volvo EX40 Ultra Single Motor Extended Range ranks 2 of 15 small SUV EVs priced within $10,000 of it for DC fast charging power.

DC fast charging rank for small SUV EVs priced near the Volvo EX40 Ultra Single Motor Extended Range
RankVehiclePricePeak DC (kW)10–80% time
1Volvo EC40 Ultra Single Motor Extended Range$76,99020528 min
2Volvo EX40 Ultra Single Motor Extended Range$76,99020028 min
2Volvo EX40 Ultra Twin Motor Performance$81,99020028 min
4Smart #1 BRABUS$67,90015028 min
4Volvo EX30 Twin Motor Performance$69,99015028 min

Volvo EX40 Ultra Single Motor Extended Range 500 km and 1,000 km Road Trips

Using Zecar's estimated highway range of 449 km and an average of 100 km/h: A 500 km trip needs 1 fast charging stop of about 28 minutes, for a total trip time of about 5 hr 28 min. A 1,000 km trip needs 2 fast charging stops of about 28 minutes each, 56 min in total, for a total trip time of about 10 hr 56 min.

Estimated road trip charging for the Volvo EX40 Ultra Single Motor Extended Range
TripCharging stopsCharging timeTotal trip time
500 km128 min5 hr 28 min
1,000 km256 min10 hr 56 min

Total trip time is driving at an average of 100 km/h plus charging time. Estimates assume a start at 100%, arrival at no less than 10% and charging from 10% to 80% at a 150 kW-capable charger. Real times vary with weather, speed, load and charger.

Plan your trip costs with the EV charging calculator →

Volvo EX40 Ultra Single Motor Extended Range Bidirectional Charging (V2X): V2L, V2H and V2G

  • V2L powers appliances from the car's socket.
  • V2H powers your home during an outage or peak pricing.
  • V2G sends energy back to the grid.
Volvo EX40 Ultra Single Motor Extended Range bidirectional charging support
FeatureSupportedMax Output
V2LNo
V2HNo
V2GNo

The Volvo EX40 Ultra Single Motor Extended Range does not support bidirectional charging.

Volvo EX40 Ultra Single Motor Extended Range Deals and Finance

Pricing starts from $76,990. A novated lease lets you pay for the car and its running costs from your pre-tax salary, and eligible EVs are exempt from fringe benefits tax. How the EV FBT exemption works

Get a Novated Lease Quote

Volvo EX40 Ultra Single Motor Extended Range Charging FAQ
