Mazda MX-30 E35 ASTINA

Mazda MX-30 E35 ASTINA Charging Speed, Time and Cost

Small SUV · 2021 – 2023FBT exempt

Usable Battery
30kWh
AC Charging
11kW
DC Charging
50kW
10–80% Time
39min

The Mazda MX-30 E35 ASTINA charges at up to 50 kW on a DC fast charger and 11 kW on AC. It takes about 39 minutes to charge from 10 to 80% and 4.5 hours to charge from empty on a 7 kW home charger. It has a 30 kWh NMC battery.

Mazda MX-30 E35 ASTINA Key Battery and Charging Specs

Mazda MX-30 E35 ASTINA battery and charging specs
Usable Battery30 kWh
Battery ChemistryNMC
Charge PortType 2 (AC), CCS2 (DC)
Charge Port LocationRight Side (Rear)
0 to 100% at Home (7 kW)4.5 hrs
Efficiency150 Wh/km

The Mazda MX-30 E35 ASTINA uses a 30 kWh NMC battery. For daily driving, charge to 80 to 90% and save 100% for long trips (LFP vs NMC vs NCA batteries explained). Check your owner's manual for Mazda's advice.

Compare the best home EV charger in Australia and work out how much electric car charging costs for your driving.

Mazda MX-30 E35 ASTINA Charging Times

Mazda MX-30 E35 ASTINA Max Charging Speed

Mazda MX-30 E35 ASTINA maximum charging speed
TypeMax Speed
AC charging speed11 kW
DC charging speed (peak)50 kW

How Long Does a Mazda MX-30 E35 ASTINA Take to Charge?

Power point, wall charger and DC fast charger for the Mazda MX-30 E35 ASTINA
Mazda MX-30 E35 ASTINA charging times by charger
ChargerPower UsedTimeRange Added
10A power point (2.3 kW)2.3 kW13.8 hrs (0 to 100%)15 km per hour
15A power point (3.6 kW)3.6 kW8.8 hrs (0 to 100%)24 km per hour
7 kW home wall charger7 kW4.5 hrs (0 to 100%)47 km per hour
11 kW three-phase charger11 kW2.9 hrs (0 to 100%)73 km per hour
50 kW DC fast charger31.9 kW39 min (10 to 80%)53 km in 15 min

Icons: grey = power point, green outline = home charger, dark = public DC fast charger.

Best Home Charger for the Mazda MX-30 E35 ASTINA

A 7 kW single-phase wall charger suits the Mazda MX-30 E35 ASTINA. It charges the battery from empty to full in 4.5 hrs and adds about 47 km of range every hour. If your home already has three-phase power, an 11 kW charger uses the Mazda MX-30 E35 ASTINA's full AC speed and charges it in 2.9 hrs.

Find the Right Charger for Your Mazda MX-30 E35 ASTINA

See the real charging speed each home charger gets with this car. 3 quick questions.

Home chargers for the Mazda MX-30 E35 ASTINA
Detail7 kW Single Phase11 kW Three Phase
0 to 100%4.5 hrs2.9 hrs
Range per hour47 km73 km
Needs three-phase powerNoYes
Typical installed cost$1,200 to $2,800$1,800 to $3,500 with existing three-phase power. $4,000 to $12,000+ if your home needs converting

Installed costs are indicative for Australia and include the charger and standard installation. A switchboard upgrade, if needed, can add $900 to $3,500.

Does the Mazda MX-30 E35 ASTINA Come With a Charger?

New EVs like the Mazda MX-30 E35 ASTINA normally come with a complimentary portable charger that plugs into a standard 10A power point. It's handy for top-ups but takes about 13.8 hrs to fully charge the battery. A 7 kW wall charger does it in 4.5 hrs.

How Much Does It Cost to Charge a Mazda MX-30 E35 ASTINA?

A full charge costs $2.10 at home on an EV plan at $0.07/kWh, and $10.50 on a typical flat tariff of $0.35/kWh. At a public DC charger at up to $0.70/kWh it costs $21.00. A petrol small SUV uses about 7.5 L/100 km, which at $2.00 a litre costs $15.00 per 100 km.

Cost to charge the Mazda MX-30 E35 ASTINA compared with a petrol small SUV
Where You ChargeFull ChargePer 100 kmPer YearSaving vs Petrol
Petrol small SUVNot applicable$15.00$2,250Not applicable
Home, flat rate $0.35/kWh$10.50$5.25$788$1,462
Home, EV plan $0.07/kWh$2.10$1.05$158$2,092
Public DC $0.70/kWh$21.00$10.50$1,575$675

Icons: grey = petrol, green outline = home charging, dark = public charging.

Per year is based on 15,000 km a year.

Switching from a flat tariff to an EV plan saves about $630 a year on charging the Mazda MX-30 E35 ASTINA at home.

Mazda MX-30 E35 ASTINA Fast Charging Rank and Road Trip Charging

The Mazda MX-30 E35 ASTINA ranks 12 of 12 small SUV EVs priced within $10,000 of it for DC fast charging power.

DC fast charging rank for small SUV EVs priced near the Mazda MX-30 E35 ASTINA
RankVehiclePricePeak DC (kW)10–80% time
1Smart #1 Premium$58,90015028 min
1Volvo EX30 Single Motor Extended$64,99015028 min
1Smart #1 BRABUS$67,90015028 min
1Volvo EX30 Twin Motor Performance$69,99015028 min
5Renault Megane E-Tech Techno$64,99013030 min
12Mazda MX-30 E35 ASTINA$65,4905039 min

Mazda MX-30 E35 ASTINA 500 km and 1,000 km Road Trips

Using Zecar's estimated highway range of 156 km and an average of 100 km/h: A 500 km trip needs 4 fast charging stops of about 39 minutes each, 2 hr 36 min in total, for a total trip time of about 7 hr 36 min. A 1,000 km trip needs 8 fast charging stops of about 39 minutes each, 5 hr 12 min in total, for a total trip time of about 15 hr 12 min.

Estimated road trip charging for the Mazda MX-30 E35 ASTINA
TripCharging stopsCharging timeTotal trip time
500 km42 hr 36 min7 hr 36 min
1,000 km85 hr 12 min15 hr 12 min

Total trip time is driving at an average of 100 km/h plus charging time. Estimates assume a start at 100%, arrival at no less than 10% and charging from 10% to 80% at a 50 kW-capable charger. Real times vary with weather, speed, load and charger.

Plan your trip costs with the EV charging calculator →

Mazda MX-30 E35 ASTINA Bidirectional Charging (V2X): V2L, V2H and V2G

  • V2L powers appliances from the car's socket.
  • V2H powers your home during an outage or peak pricing.
  • V2G sends energy back to the grid.
Mazda MX-30 E35 ASTINA bidirectional charging support
FeatureSupportedMax Output
V2LNo
V2HNo
V2GNo

The Mazda MX-30 E35 ASTINA does not support bidirectional charging.
