Kia EV9 Air RWD Charging Guide: Time, Speed, Power
Price: $97,000
Available since 2023
Variants
Key EV Specs
76.1kWh
Battery Size (capacity)
443 km
Range (WLTP)
164 Wh/km
Efficiency
8.2 s
Acceleration (0-100 km/hr)
10.5 kW AC / 240 kW DC
Charge Power (max)
Kia EV9 Air RWD Charging Overview and Charging Specs
The Kia EV9 Air RWD is equipped with a 76.1 kWh battery and supports both AC and DC charging. With the right setup, you can charge conveniently at home or use public charging stations for faster top-ups. This guide covers charging times, costs, plug types, and tips to maximise efficiency. The EV9 Air RWD uses a Type 2 plug for AC charging and a CCS connector for DC fast charging, both standard in Australia.
| Battery size (capacity) | 76.1 kWh |
| Battery Size (useable)* | 72.8 kWh |
| Battery Chemistry | - |
| Charge Port Type | Type 2 |
| Charge Port Location | Right Side - Rear |
| Charge Power (max) | 10.5 kW |
| Charge Speed | 44 km/h |
| Charge Time (0-100%) | 10 hrs 15 mins |
Kia EV9 Air RWD Charging Times and Speeds
The Kia EV9 Air RWD has a charging limit of 10.5 kW AC. This means that a three-phase 22kW AC charger will only supply power at 10.5 kW AC. If you are using a 7.2 kW AC charger, power will be limited to 7.2 kW AC. The table below provides charging times across different charger types.
Use our EV charging calculator if you want to customise your charge level and speed.
Charging Station Comparison
| Charger Type | Power Output (Average) | 0–100% Time | 10–80% Time | Speed |
|---|---|---|---|---|
| Home AC (7kW) | 7 kW | 11.4 hr | - | 43 km/h |
| Public AC (22kW) | 10.5 kW | 7.6 hr | - | 64 km/h |
| DC Fast (50kW) | 50 kW | - | 67 min | 305 km/h |
| DC Fast (150kW) | 150 kW | - | 22 min | 915 km/h |
| Ultra-Fast DC (350kW) | 350 kW | - | 10 min | 2134 km/h |
Kia EV9 Air RWD Charging Costs & Energy Use
The cost of charging a Kia EV9 Air RWD will depend on where it is being charged. The costs of charging from home versus charging as a fast public charging station vary significantly.
The cost of fully charging a Kia EV9 Air RWD on a typical home flat energy tariff of $0.35/kWh is $26.63.
The cost of fully charging the Kia EV9 Air RWD at a fast public station, where rates as high as $0.7/kWh will be $53.27.
Use our EV charging calculator to get a personalised estimate of the charging costs for a Kia EV9 Air RWD
CCS CompatibleWhile most Tesla Superchargers in Australia now support non-Tesla EVs such as the Kia EV9 Air RWD via the CCS2 standard, always check the Tesla app for station compatibility.
Kia EV9 Air RWD Fast Charging & Tesla Supercharger Compatibility
The Kia EV9 Air RWD can charge from 10–80% in approximately 23 minutes on a high-power DC charger.
While most Tesla Superchargers in Australia now support non-Tesla EVs such as the Kia EV9 Air RWD via the CCS2 standard, always check the Tesla app for station compatibility.
Charging Specifications:
Usable Battery Capacity:
76.1 kWh
Fast Charge Power (max):
240 kW
Fast Charge Power (avg):
Not available
Max Fast Charging Speed:
810 km/h
Charge Port:
Type 2
Port Location:
Right Side (Rear)
Kia EV9 Air RWD Recommended Charge Level
The Kia EV9 Air RWD uses an NMC battery. The typical recommended charge limit is 80% to 90% for daily use and only charge to 100% for longer trips.
The recommended charge limit for NMC batteries is due to higher degradation risk from a higher state of charge.
Check your owners manual for specific recommendations for the Kia EV9 Air RWD.
Kia EV9 Air RWD Bidirectional Charging (V2G/V2H/V2L)
The Kia EV9 Air RWD currently supports bidirectional charging features such as Vehicle-to-Load (V2L).
| Feature | Supported | Max Power Output |
|---|---|---|
| Vehicle-to-Grid (V2G) | No | - |
| Vehicle-to-Home (V2H) | No | - |
| Vehicle-to-Load (V2L) | Yes | 3.6 kW |
