Mercedes-Benz EQS EQS 580 4Matic Charging Speed, Time and Cost
Medium Car · 2021 – 2023
- Usable Battery
- 107.8kWh
- AC Charging
- 11kW
- DC Charging
- 207kW
- 10–80% Time
- 28min
The Mercedes-Benz EQS EQS 580 4Matic charges at up to 207 kW on a DC fast charger and 11 kW on AC. It takes about 28 minutes to charge from 10 to 80% and 16.3 hours to charge from empty on a 7 kW home charger. It has a 107.8 kWh battery.
Mercedes-Benz EQS EQS 580 4Matic Key Battery and Charging Specs
| Usable Battery | 107.8 kWh |
|---|---|
| Charge Port | Type 2 (AC), CCS2 (DC) |
| Charge Port Location | Right Side (Rear) |
| 0 to 100% at Home (7 kW) | 16.3 hrs |
| Efficiency | 186 Wh/km |
Compare the best home EV charger in Australia and work out how much electric car charging costs for your driving.
Mercedes-Benz EQS EQS 580 4Matic Charging Times
Mercedes-Benz EQS EQS 580 4Matic Max Charging Speed
| Type | Max Speed |
|---|---|
| AC charging speed | 11 kW |
| DC charging speed (peak) | 207 kW |
How Long Does a Mercedes-Benz EQS EQS 580 4Matic Take to Charge?
| Charger | Power Used | Time | Range Added |
|---|---|---|---|
| 10A power point (2.3 kW) | 2.3 kW | 49.6 hrs (0 to 100%) | 12 km per hour |
| 15A power point (3.6 kW) | 3.6 kW | 31.7 hrs (0 to 100%) | 19 km per hour |
| 7 kW home wall charger | 7 kW | 16.3 hrs (0 to 100%) | 38 km per hour |
| 11 kW three-phase charger | 11 kW | 10.4 hrs (0 to 100%) | 59 km per hour |
| 50 kW DC fast charger | 47.5 kW | 95 min (10 to 80%) | 64 km in 15 min |
| 150 kW DC fast charger | 142.5 kW | 32 min (10 to 80%) | 192 km in 15 min |
| 350 kW DC ultra-fast charger | 159.4 kW | 28 min (10 to 80%) | 214 km in 15 min |
Icons: grey = power point, green outline = home charger, dark = public DC fast charger.
Best Home Charger for the Mercedes-Benz EQS EQS 580 4Matic
A 7 kW single-phase wall charger suits the Mercedes-Benz EQS EQS 580 4Matic. It charges the battery from empty to full in 16.3 hrs and adds about 38 km of range every hour. If your home already has three-phase power, an 11 kW charger uses the Mercedes-Benz EQS EQS 580 4Matic's full AC speed and charges it in 10.4 hrs.
Find the Right Charger for Your Mercedes-Benz EQS EQS 580 4Matic
See the real charging speed each home charger gets with this car. 3 quick questions.
| Detail | 7 kW Single Phase | 11 kW Three Phase |
|---|---|---|
| 0 to 100% | 16.3 hrs | 10.4 hrs |
| Range per hour | 38 km | 59 km |
| Needs three-phase power | No | Yes |
| Typical installed cost | $1,200 to $2,800 | $1,800 to $3,500 with existing three-phase power. $4,000 to $12,000+ if your home needs converting |
Installed costs are indicative for Australia and include the charger and standard installation. A switchboard upgrade, if needed, can add $900 to $3,500.
Does the Mercedes-Benz EQS EQS 580 4Matic Come With a Charger?
New EVs like the Mercedes-Benz EQS EQS 580 4Matic normally come with a complimentary portable charger that plugs into a standard 10A power point. It's handy for top-ups but takes about 49.6 hrs to fully charge the battery. A 7 kW wall charger does it in 16.3 hrs.
How Much Does It Cost to Charge a Mercedes-Benz EQS EQS 580 4Matic?
A full charge costs $7.55 at home on an EV plan at $0.07/kWh, and $37.73 on a typical flat tariff of $0.35/kWh. At a public DC charger at up to $0.70/kWh it costs $75.46. A petrol medium car uses about 7.8 L/100 km, which at $2.00 a litre costs $15.60 per 100 km.
| Where You Charge | Full Charge | Per 100 km | Per Year | Saving vs Petrol |
|---|---|---|---|---|
| Petrol medium car | Not applicable | $15.60 | $2,340 | Not applicable |
| Home, flat rate $0.35/kWh | $37.73 | $6.51 | $977 | $1,363 |
| Home, EV plan $0.07/kWh | $7.55 | $1.30 | $195 | $2,145 |
| Public DC $0.70/kWh | $75.46 | $13.02 | $1,953 | $387 |
Icons: grey = petrol, green outline = home charging, dark = public charging.
Per year is based on 15,000 km a year.
Switching from a flat tariff to an EV plan saves about $782 a year on charging the Mercedes-Benz EQS EQS 580 4Matic at home.
Mercedes-Benz EQS EQS 580 4Matic Fast Charging Rank and Road Trip Charging
The Mercedes-Benz EQS EQS 580 4Matic charges at up to 207 kW on a DC charger.
Mercedes-Benz EQS EQS 580 4Matic 500 km and 1,000 km Road Trips
Using Zecar's estimated highway range of 505 km and an average of 100 km/h: A 500 km trip needs 1 fast charging stop of about 28 minutes, for a total trip time of about 5 hr 28 min. A 1,000 km trip needs 2 fast charging stops of about 28 minutes each, 56 min in total, for a total trip time of about 10 hr 56 min.
| Trip | Charging stops | Charging time | Total trip time |
|---|---|---|---|
| 500 km | 1 | 28 min | 5 hr 28 min |
| 1,000 km | 2 | 56 min | 10 hr 56 min |
Total trip time is driving at an average of 100 km/h plus charging time. Estimates assume a start at 100%, arrival at no less than 10% and charging from 10% to 80% at a 150 kW-capable charger. Real times vary with weather, speed, load and charger.
Plan your trip costs with the EV charging calculator →Mercedes-Benz EQS EQS 580 4Matic Bidirectional Charging (V2X): V2L, V2H and V2G
- V2L powers appliances from the car's socket.
- V2H powers your home during an outage or peak pricing.
- V2G sends energy back to the grid.
| Feature | Supported | Max Output |
|---|---|---|
| V2L | No | |
| V2H | No | |
| V2G | No |
The Mercedes-Benz EQS EQS 580 4Matic does not support bidirectional charging.
Mercedes-Benz EQS EQS 580 4Matic Charging FAQ
16.3 hrs for 0 to 100% on a 7 kW home charger, and 28 minutes for 10 to 80% at a DC charger of 207 kW or more.
11 kW on AC and 207 kW on DC, adding about 214 km of range in 15 minutes on a fast charger.
Type 2 for AC and CCS2 for DC, on the right side (rear).
$7.55 at home on an EV plan, $37.73 on a flat tariff, or $75.46 at a public DC charger (compare EV energy plans).
Yes, at Superchargers open to non-Tesla EVs, using its CCS2 plug, so check the Tesla app for which sites are open.
No, the Mercedes-Benz EQS EQS 580 4Matic does not support V2L.
