Hyundai Ioniq 5 Elite RWD Charging Guide: Time, Speed, Power
Price: $81,200
Available since 2025
Key EV Specs
84kWh
Battery Size (capacity)
570 km
Range (WLTP)
140 Wh/km
Efficiency
7.5 s
Acceleration (0-100 km/hr)
11 kW AC / 263 kW DC
Charge Power (max)
Hyundai Ioniq 5 Elite RWD Charging Overview and Charging Specs
The Hyundai Ioniq 5 Elite RWD is equipped with a 84 kWh battery and supports both AC and DC charging. With the right setup, you can charge conveniently at home or use public charging stations for faster top-ups. This guide covers charging times, costs, plug types, and tips to maximise efficiency. The Ioniq 5 Elite RWD uses a Type 2 plug for AC charging and a CCS connector for DC fast charging, both standard in Australia.
| Battery size (capacity) | 84 kWh |
| Battery Size (useable) | 80 kWh |
| Battery Chemistry | NMC |
| Charge Port Type | Type 2 |
| Charge Port Location | Left Side - Front |
| Charge Power (max) | 11 kW |
| Charge Speed | 71 km/h |
| Charge Time (0-100%) | 9 hrs |
Hyundai Ioniq 5 Elite RWD Charging Times and Speeds
The Hyundai Ioniq 5 Elite RWD has a charging limit of 11 kW AC. This means that a three-phase 22kW AC charger will only supply power at 11 kW AC. If you are using a 7.2 kW AC charger, power will be limited to 7.2 kW AC. The table below provides charging times across different charger types.
Use our EV charging calculator if you want to customise your charge level and speed.
Charging Station Comparison
| Charger Type | Power Output (Average) | 0–100% Time | 10–80% Time | Speed |
|---|---|---|---|---|
| Home AC (7kW) | 7 kW | 12.6 hr | - | 50 km/h |
| Public AC (22kW) | 11 kW | 8.0 hr | - | 79 km/h |
| DC Fast (50kW) | 50 kW | - | 74 min | 357 km/h |
| DC Fast (150kW) | 150 kW | - | 25 min | 1071 km/h |
| Ultra-Fast DC (350kW) | 350 kW | - | 11 min | 2500 km/h |
Hyundai Ioniq 5 Elite RWD Charging Costs & Energy Use
The cost of charging a Hyundai Ioniq 5 Elite RWD will depend on where it is being charged. The costs of charging from home versus charging as a fast public charging station vary significantly.
The cost of fully charging a Hyundai Ioniq 5 Elite RWD on a typical home flat energy tariff of $0.35/kWh is $29.40.
The cost of fully charging the Hyundai Ioniq 5 Elite RWD at a fast public station, where rates as high as $0.7/kWh will be $58.80.
Use our EV charging calculator to get a personalised estimate of the charging costs for a Hyundai Ioniq 5 Elite RWD
CCS CompatibleWhile most Tesla Superchargers in Australia now support non-Tesla EVs such as the Hyundai Ioniq 5 Elite RWD via the CCS2 standard, always check the Tesla app for station compatibility.
Hyundai Ioniq 5 Elite RWD Fast Charging & Tesla Supercharger Compatibility
The Hyundai Ioniq 5 Elite RWD can charge from 10–80% in approximately 17 minutes on a high-power DC charger.
While most Tesla Superchargers in Australia now support non-Tesla EVs such as the Hyundai Ioniq 5 Elite RWD via the CCS2 standard, always check the Tesla app for station compatibility.
Charging Specifications:
Usable Battery Capacity:
84 kWh
Fast Charge Power (max):
263 kW
Fast Charge Power (avg):
Not available
Max Fast Charging Speed:
1686 km/h
Charge Port:
Type 2
Port Location:
Left Side (Front)
Hyundai Ioniq 5 Elite RWD Recommended Charge Level
The Hyundai Ioniq 5 Elite RWD uses an NMC battery. The typical recommended charge limit is 80% to 90% for daily use and only charge to 100% for longer trips.
The recommended charge limit for NMC batteries is due to higher degradation risk from a higher state of charge.
Check your owners manual for specific recommendations for the Hyundai Ioniq 5 Elite RWD.
Hyundai Ioniq 5 Elite RWD Bidirectional Charging (V2G/V2H/V2L)
The Hyundai Ioniq 5 Elite RWD currently supports bidirectional charging features such as Vehicle-to-Load (V2L).
| Feature | Supported | Max Power Output |
|---|---|---|
| Vehicle-to-Grid (V2G) | No | - |
| Vehicle-to-Home (V2H) | No | - |
| Vehicle-to-Load (V2L) | Yes | 4 kW |
