XPENG X9 FWD Standard Range Charging Guide: Time, Speed, Power
Price: $89,900
Available since 2001
Key EV Specs
94.8kWh
Battery Size (capacity)
535 km
Range (WLTP)
174 Wh/km
Efficiency
7.7 s
Acceleration (0-100 km/hr)
11 kW AC / 537 kW DC
Charge Power (max)
XPENG X9 FWD Standard Range Charging Overview and Charging Specs
The XPENG X9 FWD Standard Range is equipped with a 94.8 kWh battery and supports both AC and DC charging. With the right setup, you can charge conveniently at home or use public charging stations for faster top-ups. This guide covers charging times, costs, plug types, and tips to maximise efficiency. The X9 FWD Standard Range uses a Type 2 plug for AC charging and a CCS connector for DC fast charging, both standard in Australia.
| Battery size (capacity) | 94.8 kWh |
| Battery Size (useable) | 93 kWh |
| Battery Chemistry | LFP |
| Charge Port Type | Type 2 |
| Charge Port Location | Right Side - Rear |
| Charge Power (max) | 11 kW |
| Charge Speed | - |
| Charge Time (0-100%) | 10 hrs |
XPENG X9 FWD Standard Range Charging Times and Speeds
The XPENG X9 FWD Standard Range has a charging limit of 11 kW AC. This means that a three-phase 22kW AC charger will only supply power at 11 kW AC. If you are using a 7.2 kW AC charger, power will be limited to 7.2 kW AC. The table below provides charging times across different charger types.
Use our EV charging calculator if you want to customise your charge level and speed.
Charging Station Comparison
| Charger Type | Power Output (Average) | 0–100% Time | 10–80% Time | Speed |
|---|---|---|---|---|
| Home AC (7kW) | 7 kW | 14.0 hr | - | 40 km/h |
| Public AC (22kW) | 11 kW | 8.9 hr | - | 63 km/h |
| DC Fast (50kW) | 50 kW | - | 82 min | 287 km/h |
| DC Fast (150kW) | 150 kW | - | 27 min | 862 km/h |
| Ultra-Fast DC (350kW) | 326 kW | - | 13 min | 1874 km/h |
XPENG X9 FWD Standard Range Charging Costs & Energy Use
The cost of charging a XPENG X9 FWD Standard Range will depend on where it is being charged. The costs of charging from home versus charging as a fast public charging station vary significantly.
The cost of fully charging a XPENG X9 FWD Standard Range on a typical home flat energy tariff of $0.35/kWh is $33.18.
The cost of fully charging the XPENG X9 FWD Standard Range at a fast public station, where rates as high as $0.7/kWh will be $66.36.
Use our EV charging calculator to get a personalised estimate of the charging costs for a XPENG X9 FWD Standard Range
CCS CompatibleXPENG X9 FWD Standard Range Fast Charging & Tesla Supercharger Compatibility
The XPENG X9 FWD Standard Range can charge from 10–80% in approximately 12 minutes on a high-power DC charger.
While most Tesla Superchargers in Australia now support non-Tesla EVs such as the XPENG X9 FWD Standard Range via the CCS2 standard, always check the Tesla app for station compatibility.
Charging Specifications:
Usable Battery Capacity:
94.8 kWh
Fast Charge Power (max):
537 kW
Fast Charge Power (avg):
326 kW
Max Fast Charging Speed:
2780 km/h
Charge Port:
Type 2
Port Location:
Right Side (Rear)
XPENG X9 FWD Standard Range Recommended Charge Level
The XPENG X9 FWD Standard Range uses an LFP battery. The typical recommended charge limit is 100% for daily use.
The key advantage of LFP is the freedom to fully charge the pack to 100% every time with substantially less degradation concerns compared to other chemistries.
Check your owners manual for specific recommendations for the XPENG X9 FWD Standard Range.
XPENG X9 FWD Standard Range Bidirectional Charging (V2G/V2H/V2L)
The XPENG X9 FWD Standard Range currently supports bidirectional charging features such as Vehicle-to-Load (V2L).
| Feature | Supported | Max Power Output |
|---|---|---|
| Vehicle-to-Grid (V2G) | No | - |
| Vehicle-to-Home (V2H) | No | - |
| Vehicle-to-Load (V2L) | Yes | 6 kW |
