Mercedes-Benz G-Class G580

Mercedes-Benz G-Class G580 Charging Speed, Time and Cost

Large SUV · 2025 – Current

Usable Battery
116kWh
AC Charging
11kW
DC Charging
200kW
10–80% Time
32min

The Mercedes-Benz G-Class G580 charges at up to 200 kW on a DC fast charger and 11 kW on AC. It takes about 32 minutes to charge from 10 to 80% and 17.5 hours to charge from empty on a 7 kW home charger. It has a 116 kWh NMC battery.

Mercedes-Benz G-Class G580 Key Battery and Charging Specs

Mercedes-Benz G-Class G580 battery and charging specs
Usable Battery116 kWh
Battery ChemistryNMC
Charge PortType 2 (AC), CCS2 (DC)
Charge Port LocationLeft Side (Front)
0 to 100% at Home (7 kW)17.5 hrs
Efficiency245 Wh/km

The Mercedes-Benz G-Class G580 uses a 116 kWh NMC battery. For daily driving, charge to 80 to 90% and save 100% for long trips (LFP vs NMC vs NCA batteries explained). Check your owner's manual for Mercedes-Benz's advice.

Compare the best home EV charger in Australia and work out how much electric car charging costs for your driving.

Mercedes-Benz G-Class G580 Charging Times

Mercedes-Benz G-Class G580 Max Charging Speed

Mercedes-Benz G-Class G580 maximum charging speed
TypeMax Speed
AC charging speed11 kW
DC charging speed (peak)200 kW

How Long Does a Mercedes-Benz G-Class G580 Take to Charge?

Power point, wall charger and DC fast charger for the Mercedes-Benz G-Class G580
Mercedes-Benz G-Class G580 charging times by charger
ChargerPower UsedTimeRange Added
10A power point (2.3 kW)2.3 kW53.4 hrs (0 to 100%)9 km per hour
15A power point (3.6 kW)3.6 kW34.1 hrs (0 to 100%)15 km per hour
7 kW home wall charger7 kW17.5 hrs (0 to 100%)29 km per hour
11 kW three-phase charger11 kW11.2 hrs (0 to 100%)45 km per hour
50 kW DC fast charger47.5 kW103 min (10 to 80%)48 km in 15 min
150 kW DC fast charger142.5 kW34 min (10 to 80%)145 km in 15 min
350 kW DC ultra-fast charger152.3 kW32 min (10 to 80%)155 km in 15 min

Icons: grey = power point, green outline = home charger, dark = public DC fast charger.

Best Home Charger for the Mercedes-Benz G-Class G580

A 7 kW single-phase wall charger suits the Mercedes-Benz G-Class G580. It charges the battery from empty to full in 17.5 hrs and adds about 29 km of range every hour. If your home already has three-phase power, an 11 kW charger uses the Mercedes-Benz G-Class G580's full AC speed and charges it in 11.2 hrs.

Find the Right Charger for Your Mercedes-Benz G-Class G580

See the real charging speed each home charger gets with this car. 3 quick questions.

Home chargers for the Mercedes-Benz G-Class G580
Detail7 kW Single Phase11 kW Three Phase
0 to 100%17.5 hrs11.2 hrs
Range per hour29 km45 km
Needs three-phase powerNoYes
Typical installed cost$1,200 to $2,800$1,800 to $3,500 with existing three-phase power. $4,000 to $12,000+ if your home needs converting

Installed costs are indicative for Australia and include the charger and standard installation. A switchboard upgrade, if needed, can add $900 to $3,500.

Does the Mercedes-Benz G-Class G580 Come With a Charger?

New EVs like the Mercedes-Benz G-Class G580 normally come with a complimentary portable charger that plugs into a standard 10A power point. It's handy for top-ups but takes about 53.4 hrs to fully charge the battery. A 7 kW wall charger does it in 17.5 hrs.

How Much Does It Cost to Charge a Mercedes-Benz G-Class G580?

A full charge costs $8.12 at home on an EV plan at $0.07/kWh, and $40.60 on a typical flat tariff of $0.35/kWh. At a public DC charger at up to $0.70/kWh it costs $81.20. A petrol large SUV uses about 11.5 L/100 km, which at $2.00 a litre costs $23.00 per 100 km.

Cost to charge the Mercedes-Benz G-Class G580 compared with a petrol large SUV
Where You ChargeFull ChargePer 100 kmPer YearSaving vs Petrol
Petrol large SUVNot applicable$23.00$3,450Not applicable
Home, flat rate $0.35/kWh$40.60$8.58$1,286$2,164
Home, EV plan $0.07/kWh$8.12$1.72$257$3,193
Public DC $0.70/kWh$81.20$17.15$2,573$877

Icons: grey = petrol, green outline = home charging, dark = public charging.

Per year is based on 15,000 km a year.

Switching from a flat tariff to an EV plan saves about $1,029 a year on charging the Mercedes-Benz G-Class G580 at home.

Mercedes-Benz G-Class G580 Fast Charging Rank and Road Trip Charging

The Mercedes-Benz G-Class G580 charges at up to 200 kW on a DC charger.

Mercedes-Benz G-Class G580 500 km and 1,000 km Road Trips

Using Zecar's estimated highway range of 369 km and an average of 100 km/h: A 500 km trip needs 1 fast charging stop of about 32 minutes, for a total trip time of about 5 hr 32 min. A 1,000 km trip needs 3 fast charging stops of about 32 minutes each, 1 hr 36 min in total, for a total trip time of about 11 hr 36 min.

Estimated road trip charging for the Mercedes-Benz G-Class G580
TripCharging stopsCharging timeTotal trip time
500 km132 min5 hr 32 min
1,000 km31 hr 36 min11 hr 36 min

Total trip time is driving at an average of 100 km/h plus charging time. Estimates assume a start at 100%, arrival at no less than 10% and charging from 10% to 80% at a 150 kW-capable charger. Real times vary with weather, speed, load and charger.

Plan your trip costs with the EV charging calculator →

Mercedes-Benz G-Class G580 Bidirectional Charging (V2X): V2L, V2H and V2G

  • V2L powers appliances from the car's socket.
  • V2H powers your home during an outage or peak pricing.
  • V2G sends energy back to the grid.
Mercedes-Benz G-Class G580 bidirectional charging support
FeatureSupportedMax Output
V2LNo
V2HNo
V2GNo

The Mercedes-Benz G-Class G580 does not support bidirectional charging.
