GWM Ora 5 SUV Lux Charging Guide: Time, Speed, Power
Price: $33,990
Available since 2026
Variants
Key EV Specs
60kWh
Battery Size (capacity)
430 km
Range (WLTP)
136 Wh/km
Efficiency
9 s
Acceleration (0-100 km/hr)
11 kW AC / 120 kW DC
Charge Power (max)
GWM Ora 5 SUV Lux Charging Overview and Charging Specs
The GWM Ora 5 SUV Lux is equipped with a 60 kWh battery and supports both AC and DC charging. With the right setup, you can charge conveniently at home or use public charging stations for faster top-ups. This guide covers charging times, costs, plug types, and tips to maximise efficiency. The Ora 5 SUV Lux uses a Type 2 plug for AC charging and a CCS connector for DC fast charging, both standard in Australia.
| Battery size (capacity) | 60 kWh |
| Battery Size (useable) | 58.3 kWh |
| Battery Chemistry | LFP |
| Charge Port Type | Type 2 |
| Charge Port Location | Left Side - Front |
| Charge Power (max) | 11 kW |
| Charge Speed | 73 km/h |
| Charge Time (0-100%) | 6 hrs |
GWM Ora 5 SUV Lux Charging Times and Speeds
The GWM Ora 5 SUV Lux has a charging limit of 11 kW AC. This means that a three-phase 22kW AC charger will only supply power at 11 kW AC. If you are using a 7.2 kW AC charger, power will be limited to 7.2 kW AC. The table below provides charging times across different charger types.
Use our EV charging calculator if you want to customise your charge level and speed.
Charging Station Comparison
| Charger Type | Power Output (Average) | 0–100% Time | 10–80% Time | Speed |
|---|---|---|---|---|
| Home AC (7kW) | 7 kW | 8.8 hr | - | 51 km/h |
| Public AC (22kW) | 11 kW | 5.6 hr | - | 81 km/h |
| DC Fast (50kW) | 50 kW | - | 52 min | 368 km/h |
| DC Fast (150kW) | 82 kW | - | 31 min | 603 km/h |
| Ultra-Fast DC (350kW) | 82 kW | - | 31 min | 603 km/h |
GWM Ora 5 SUV Lux Charging Costs & Energy Use
The cost of charging a GWM Ora 5 SUV Lux will depend on where it is being charged. The costs of charging from home versus charging as a fast public charging station vary significantly.
The cost of fully charging a GWM Ora 5 SUV Lux on a typical home flat energy tariff of $0.35/kWh is $21.00.
The cost of fully charging the GWM Ora 5 SUV Lux at a fast public station, where rates as high as $0.7/kWh will be $42.00.
Use our EV charging calculator to get a personalised estimate of the charging costs for a GWM Ora 5 SUV Lux
CCS CompatibleGWM Ora 5 SUV Lux Fast Charging & Tesla Supercharger Compatibility
The GWM Ora 5 SUV Lux can charge from 10–80% in approximately 30 minutes on a high-power DC charger.
While most Tesla Superchargers in Australia now support non-Tesla EVs such as the GWM Ora 5 SUV Lux via the CCS2 standard, always check the Tesla app for station compatibility.
Charging Specifications:
Usable Battery Capacity:
60 kWh
Fast Charge Power (max):
120 kW
Fast Charge Power (avg):
82 kW
Max Fast Charging Speed:
797 km/h
Charge Port:
Type 2
Port Location:
Left Side (Front)
GWM Ora 5 SUV Lux Recommended Charge Level
The GWM Ora 5 SUV Lux uses an LFP battery. The typical recommended charge limit is 100% for daily use.
The key advantage of LFP is the freedom to fully charge the pack to 100% every time with substantially less degradation concerns compared to other chemistries.
Check your owners manual for specific recommendations for the GWM Ora 5 SUV Lux.
GWM Ora 5 SUV Lux Bidirectional Charging (V2G/V2H/V2L)
The GWM Ora 5 SUV Lux currently supports bidirectional charging features such as Vehicle-to-Load (V2L).
| Feature | Supported | Max Power Output |
|---|---|---|
| Vehicle-to-Grid (V2G) | No | - |
| Vehicle-to-Home (V2H) | No | - |
| Vehicle-to-Load (V2L) | Yes | 6 kW |
