Leapmotor B10 Design Charging Guide: Time, Speed, Power
Price: $41,990
Available since 2024
Variants
Key EV Specs
67.1kWh
Battery Size (capacity)
434 km
Range (WLTP)
155 Wh/km
Efficiency
8 s
Acceleration (0-100 km/hr)
11 kW AC / 168 kW DC
Charge Power (max)
Leapmotor B10 Design Charging Overview and Charging Specs
The Leapmotor B10 Design is equipped with a 67.1 kWh battery and supports both AC and DC charging. With the right setup, you can charge conveniently at home or use public charging stations for faster top-ups. This guide covers charging times, costs, plug types, and tips to maximise efficiency. The B10 Design uses a Type 2 plug for AC charging and a CCS connector for DC fast charging, both standard in Australia.
| Battery size (capacity) | 67.1 kWh |
| Battery Size (useable) | 67.1 kWh |
| Battery Chemistry | LFP |
| Charge Port Type | Type 2 |
| Charge Port Location | Right Side - Rear |
| Charge Power (max) | 11 kW |
| Charge Speed | 23 km/h |
| Charge Time (0-100%) | 7 hrs |
Leapmotor B10 Design Charging Times and Speeds
The Leapmotor B10 Design has a charging limit of 11 kW AC. This means that a three-phase 22kW AC charger will only supply power at 11 kW AC. If you are using a 7.2 kW AC charger, power will be limited to 7.2 kW AC. The table below provides charging times across different charger types.
Use our EV charging calculator if you want to customise your charge level and speed.
Charging Station Comparison
| Charger Type | Power Output (Average) | 0–100% Time | 10–80% Time | Speed |
|---|---|---|---|---|
| Home AC (7kW) | 7 kW | 10.1 hr | - | 45 km/h |
| Public AC (22kW) | 11 kW | 6.4 hr | - | 71 km/h |
| DC Fast (50kW) | 50 kW | - | 59 min | 323 km/h |
| DC Fast (150kW) | 88 kW | - | 34 min | 568 km/h |
| Ultra-Fast DC (350kW) | 88 kW | - | 34 min | 568 km/h |
Leapmotor B10 Design Charging Costs & Energy Use
The cost of charging a Leapmotor B10 Design will depend on where it is being charged. The costs of charging from home versus charging as a fast public charging station vary significantly.
The cost of fully charging a Leapmotor B10 Design on a typical home flat energy tariff of $0.35/kWh is $23.48.
The cost of fully charging the Leapmotor B10 Design at a fast public station, where rates as high as $0.7/kWh will be $46.97.
Use our EV charging calculator to get a personalised estimate of the charging costs for a Leapmotor B10 Design
CCS CompatibleLeapmotor B10 Design Fast Charging & Tesla Supercharger Compatibility
The Leapmotor B10 Design can charge from 10–80% in approximately 32 minutes on a high-power DC charger.
While most Tesla Superchargers in Australia now support non-Tesla EVs such as the Leapmotor B10 Design via the CCS2 standard, always check the Tesla app for station compatibility.
Charging Specifications:
Usable Battery Capacity:
67.1 kWh
Fast Charge Power (max):
168 kW
Fast Charge Power (avg):
88 kW
Max Fast Charging Speed:
541 km/h
Charge Port:
Type 2
Port Location:
Right Side (Rear)
Leapmotor B10 Design Recommended Charge Level
The Leapmotor B10 Design uses an LFP battery. The typical recommended charge limit is 100% for daily use.
The key advantage of LFP is the freedom to fully charge the pack to 100% every time with substantially less degradation concerns compared to other chemistries.
Check your owners manual for specific recommendations for the Leapmotor B10 Design.
Leapmotor B10 Design Bidirectional Charging (V2G/V2H/V2L)
The Leapmotor B10 Design currently supports bidirectional charging features such as Vehicle-to-Load (V2L).
| Feature | Supported | Max Power Output |
|---|---|---|
| Vehicle-to-Grid (V2G) | No | - |
| Vehicle-to-Home (V2H) | No | - |
| Vehicle-to-Load (V2L) | Yes | 3.3 kW |
